· PLC control, touch screen user interface.
· Rotation speed and conveyor speed variable, overlapping width could be adjusted according to requirements.
· Pneumatically driven pressing devices effectively hold the products during wrapping.
· Swing ring structure ring for quieter use environment and increased reliability. *Photocell automatically senses the products and starts wrapping. Auto film clamp & cut.
| Product Parameters | ||||
| Ring Diameter | 900mm | Conveyor Length | made to order | |
| Wrapping Size | 550mm*550mm | Power | 0.75kw+conveyor | |
| Wrapping Length | ≥700mm，Unlimited length | Machine voltage | 380V,50/60HZ,20A | |
| Rotation Speed | 20-60rpm,variable | Control | PLC programmable control | |
| Conveyor Speed | 5-8m，variable | Working Mode | auto | |
