Description
Application –
- Online Batch Coding on – Pouch / Label / Laminate / Mono Carton / Pet Bottle.
- Online Large Character Printing on – Shipper Carton / HDPE Bag.
- Online 2D / QR code Printing on – Carton / Label / Pouch / Label.
Technical Specification –
| Parameter | Specification |
|---|---|
| Printing Technology | Thermal Inkjet Technology – Industrial Grade |
| Operating System | Embedded Operating System |
| Controller Dimensions (L × W × H) | 193 × 130.3 × 34.5 mm |
| Print Head Dimensions (L × W × H) | 210.4 × 60.8 × 74.15 mm |
| Display | 7-inch Touch Screen |
| Power Supply | AC 100V–240V, 50/60Hz, DC 24V 2.5A |
| Resolution | Maximum 300 × 600 dpi |
| Print Speed | Maximum 80 m/min @ 300 × 300 dpi |
| Throw Distance | 2 mm to 5 mm |
| Message Height | 1.5 mm to 12.5 mm with ½-inch print head; up to 50 mm with multi print head |
| Printing Capability | Alphanumeric Text, Image, Simple Logo, 2D Matrix Code, QR Code, Counter |
| Available Ink | Water-based Ink & Solvent-based Ink for porous and non-porous surfaces |
| Operating Temperature | 5°C to 50°C @ 90% Air Humidity |
